Products Detailed Description
| Actuation Pressure | 4Mpa - 9.5Mpa(40kgf/cm2 - 95kgf/cm2) |
|---|---|
| Applicable Spindle | Through spindle coolant system |
| Application | Operate with HINAKA BPF Series, For Machining Centers Unclamping Use, Other equipmentsEngineering,Vehicle Engineering,Industry,CNC center,Bionic,Robot |
| Customization | Stroke, Sensor,Cylinder Installation |
| Cylinder Diameter | Φ115 mm |
| Output Force | 155Mpa - 760Mpa(1550kgf/cm2 - 7600kgf/cm2) |
| Sensor | without sensor |
| Stroke | 13 mm |
| Temperature Range | (0) ~ (+60)℃ |
| Working Fluid | CPC-R32 / ISO VG32 |
Two-piece Proximity Switch Fixing Piece
Proximity Switch(OMRON)
Proximity Switch(RIKO)
Single Proximity Switch Fixing Piece
L-shaped Fixing Plate
Micro Switch(OMRON)
