Solenoid Valve – HPS Series
HPS solenoid valve: poppet-type 3/2 and 4/2 valves for large flow and fast response. The 5/2 valve returns by air pressure instead of a spring, unlike the spring-return designs most valves use, so there is no spring to fatigue or wear out.
Solenoid Valve
- 3port-2position and 4port-2position solenoid valves are designed with a poppet type, with large displacement and quick response.
- The 5port-2position solenoid valve returns by air pressure instead of a spring, unlike the spring-return designs most valves use, so there is no spring fatigue or friction wear.
- Low starting force, anti-wear and anti-rust design, can be used for a long time in harsh processing environment.
- Diversified installation and piping methods, convenient and simple to use.
DOWNLOAD
 | Product Name | Actuation Pressure | Air Pipe | Reaction Time | Sensor | Stress Resistant | Voltage | Working Fluid | Compare |
| HPS321S-2B | 2kgf/cm2 - 7kgf/cm2 | PT1/8 | 10 - 15ms | with sensor | 10 kgf/cm2 | AC110V, AC220V, DC24V | Air |
 | Product Name | Actuation Pressure | Air Pipe | Reaction Time | Sensor | Stress Resistant | Voltage | Working Fluid | Compare |
| HPS424S-2B | 2kgf/cm2 - 7kgf/cm2 | PT1/2 | ON-4.9ms / OFF-4.4ms | with sensor | 10 kgf/cm2 | AC110V, AC220V, DC24V | Air |
 | Product Name | Actuation Pressure | Air Pipe | Reaction Time | Sensor | Stress Resistant | Voltage | Working Fluid | Compare |
| HPS523S-2B | 2kgf/cm2 - 7kgf/cm2 | PT3/8 | 10 - 15ms | with sensor | 10 kgf/cm2 | AC110V, AC220V, DC24V | Air |
